Legend:
SEA-Mini: Acoustic emission sensor
SEA-Feder: SEA-Mini with spring steel element as wave guide
SNF-SEA: Super low frequency vibration pickup
SEH: Acoustic emission sensor via coolant lubricant jet
BSA: Electromagnetic acoustic emission sensor
RSA(-2,-Ring): Rotating sensor with non-contact transmission
LSM: Airborne noise microphone
SDS-Fork: Fork barriers for short coolant or air jets
SDS-Kanone: Solid jet barrier with long free coolant jet
APS-L or -Q: Strike sensor
APS-BDA:
WLM-3: Three-phase active power measurement unit
3D-KMS: Three-dimensional measurement piezo quarz orifice plate
BDA-Q: Deflection sensor for feed force measurement
BDA-Kralle: Strain sensor for feed force measurement
BDA-L-Mini: Eddy current position sensor for feed force measurement
DMA: No-contact torque pickup
HDS: Hydro-distance sensor for distance measurement via coolant jet
WLT: Work piece length control measurement
Profibus: Sensorless measurement
EMS-Dyn:
EMS-Ind:
PCS-100:
DMA:
DMS-Kralle:
